Product Description

* Aluminium frame width 48mm–120mm.
* Can be manufactured as single doors or double doors (french doors)
* Single door sizes up to 900mm in width, and up to 2700mm in height
* Double door sizes up to 1800mm wide and 2700mm in height
* Available in anodised or powder-coated aluminium in all RAL color.
* Available in standard 5mm+9A+5mm doulbe glass, toughened glass or laminated safety glass.


Optional Features
* EPDM gasket or sealant optional.
* Single glass or double glass optional
* Open inwards or outwards optional
* Choice of high-end door handles, including D-handles.

General description:

Aluminium doors with hinges are likely the most common sort of door; they can open inward or outward and are attached to the door frame on either the left or right side.
This device is adaptable and can be utilised as a household entrance door in a business or office setting. The product’s flexibility enables the door to be inserted into a bigger shopfront piece. The product may also include sidelights and fittings.
The French door can open inside or outwardly. Some have grid patterns, whereas others don’t. A one-panel door is perfect for smaller areas, while two doors that meet in the middle and may be used alone or in conjunction with sidelights to let in more natural light and ventilation, really open up your room.

Tech Specs

Product Detail

* Aluminium alloy 6063-T5, high tech profile and renforce material
*High quality glass fiber thermal break insulation bar with high loading capacity
*10-15 years warranty in powdercoating surface treatment
*Multi-point hardware lock system for weather sealing and burglarproofing
*Corner locking key ensures the smooth surface joint and improves corner stability
*Glass panel EPDM foam weather sealing strip used for better performance and easier maintenance than standard glue



Surface Treatment: Customized (Powder coated/ Electrophoresis/ Anodizing etc).

Color: Customized (White, black, silver etc any color is available by INTERPON or COLOR BOND).

White Aluminium french swing door



Specifications Of Glass

1. Single Glazing: 4/5/6/8/10/12/15/19mm Etc

2. Double Glazing: 5mm+12a+5mm ,6mm+12a+6mm ,8mm+12a +8mm,can be Sliver Or Black Spacer

3. Laminated Glazing: 3mm+0.38pvb+3mm, 5mm+0.76pvb+5mm, 6mm+1.14pvb+6mm
Tempered ,clear, Tinted, Low-E, Reflective, Forsted.

4. With AS/nzs2208, As/nz1288 Certification



White Aluminium french swing door



Specifications of Screen

1. Stainless Steel 304/316

2. Firber Screen


White Aluminium french swing door


Specifications of Hardware

1.China top Kinlong hardware
2.America CMECH hardware
3.German Hoppe hardware
4.China top PAG Hardware
5.German SIEGENIA hardware
6.German ROTO hardware
7.German GEZE hardware
8.Aluwin choose seriously hardwares&accessories for customers with 10 years warranty

White Aluminium french swing door
