PRODUCT

Lift&Sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door
aluminium frame balcony glass sliding door

aluminium frame balcony glass sliding door

Product Description

* Aluminium frame two track width 130mm, three track frame width196mm.
* Popular two track and three track sliding make it more suitalbe for balcony area.
* Two track system designed for two panel or four panel sliding.
* Two panel sliding door or three panels sizes up to 3000mm in width, and up to 2400mm in height.
* Four panel sliding door sizes up to 6000mm in width, and up to 2400mm in height.
* Available in anodised or powder-coated aluminium in all RAL color.
* Available in standard 6mm glass to 24mm,toughened glass or laminated safety glass.
* Glass can be tinted in a range of colours.
Optional Features
* Colonial bars and grids may be present or absent.
* Including or excluding a fibre mosquito screen.
* Optional sealant or EPDM gasket.
* Different types lock for choice. Consult for detailed.

General description:

Heavy duty balcony sliding door suitable for garden doors, entrance and large balcony if high-end apartment and villas.  It looks luxury and modern.

Tech Specs
Color
Glass
Srceens
Hardware

Product Detail

* Aluminium alloy 6063-T5, high tech profile and renforce material
*High quality glass fiber thermal break insulation bar with high loading capacity
*10-15 years warranty in powdercoating surface treatment
*Multi-point hardware lock system for weather sealing and burglarproofing
*Corner locking key ensures the smooth surface joint and improves corner stability
*Glass panel EPDM foam weather sealing strip used for better performance and easier maintenance than standard glue

Color



Surface Treatment: Customized (Powder coated/ Electrophoresis/ Anodizing etc).

Color: Customized (White, black, silver etc any color is available by INTERPON or COLOR BOND).

aluminium frame balcony glass sliding door

Glass



Specifications Of Glass

1. Single Glazing: 4/5/6/8/10/12/15/19mm Etc

2. Double Glazing: 5mm+12a+5mm ,6mm+12a+6mm ,8mm+12a +8mm,can be Sliver Or Black Spacer

3. Laminated Glazing: 3mm+0.38pvb+3mm, 5mm+0.76pvb+5mm, 6mm+1.14pvb+6mm
Tempered ,clear, Tinted, Low-E, Reflective, Forsted.

4. With AS/nzs2208, As/nz1288 Certification





aluminium frame balcony glass sliding door

Screen



Specifications of Screen

1. Stainless Steel 304/316

2. Firber Screen



aluminium frame balcony glass sliding door

Hardware

Specifications of Hardware

1.China top Kinlong hardware
2.America CMECH hardware
3.German Hoppe hardware
4.China top PAG Hardware
5.German SIEGENIA hardware
6.German ROTO hardware
7.German GEZE hardware
8.Aluwin choose seriously hardwares&accessories for customers with 10 years warranty

aluminium frame balcony glass sliding door

Why Choose Us

Customized - We are an aluminium manufacturer with more than 15 years of fruitful and beneficial experience in this field. For your engineer and design requirements, our experts present the most qualified and cost-effective proposals, offering solutions for projects of varied sizes and complexity.



Technical Support -Technical assistance (such as wind load calculations, system and façade optimisation), and installation instructions are provided by independent local and international technology teams for aluminium curtain walls.



System design -Develop new aluminium window and door systems with top-notch accessories to better suit the needs of the client target market based on the demands of the market and the client.
